Microsoft® SQL™ Server AutoCAD Electrical toolset also supports SQL Server for your catalog data information. AutoCAD Electrical toolset allows you to migrate the catalog data that is furnished with the default AutoCAD Electrical toolset installation in a Microsoft Access database file.

You can either configure and set up your SQL Server instance when you are installing AutoCAD Electrical toolset or use the AECATALOGCONFIG command, later, to set your catalog database source. Currently, the support is limited to catalog and footprint databases for SQL Server. Miscellaneous Text Files WDDESC.WDD Lists various standard component description selections, accessible by clicking Defaults on the Insert/Edit dialog boxes.

WDFAM.DAT Maps the family codes to new values, overriding the family tag code of the library symbols. DEFAULT.WDT Attribute mapping file for Title Block update.

DEFAULT.WDA User-defined attribute list used in reports. DEFAULTWDTITLE.WDL Customizes the generic LINEx labels in the various title block and project information dialog boxes.

Ugly's Electrical Reference Guide

DEFAULT.INST, DEFAULT.LOC Lists the default installation and location codes, accessible by clicking Project in the Installation or location section of the Insert/Edit dialog boxes. Schematic Symbol Naming Convention.

The first character is either 'H' or 'V' for horizontal or vertical wire insertion. The next two characters are reserved for family type (for example, PB for push buttons, CR for control relays, LS for limit switches). The fourth character is generally a 2 for child contacts and 1 for everything else (parent or standalone component).

Electrical Quick Reference Guide

Lewies Little Electrical Reference Guide

If the symbol is a contact, then the fifth character is a 1 for normally open, 2 for normally closed. The remaining characters are not specified. They are used to keep names unique. Symbol names are limited to 32 characters.
